A Veneer Collector Machine, also known as a Veneer Stacker or Automatic Veneer Stacking Machine, is an industrial woodworking machine designed to collect, align, sort, and automatically stack veneer sheets.
It is typically installed after the veneer peeling machine in a plywood or LVL production line. The machine transfers thin wood veneers from the peeling knife outlet, arranges them in an orderly direction, and stacks them neatly for subsequent processes such as veneer drying, veneer jointing, or hot pressing.
Common English names include:
Veneer Stacker
Veneer Collector
Automatic Veneer Stacking Machine
Veneer Conveyor and Stacking System
The veneer stacker automatically collects veneers discharged from the veneer peeling machine and stacks them neatly according to a preset orientation, ensuring consistent veneer alignment and stable stacking.
Some veneer collector machines are equipped with grading and sorting systems, allowing veneers to be sorted by length, width, or quality grades (A/B/C) and stacked separately to meet different production requirements.
Traditional veneer handling relies heavily on manual labor. An automatic veneer stacking machine significantly reduces labor intensity, improves production efficiency, and minimizes handling damage.
The veneer collector can be directly connected with veneer peeling machines, veneer dryers, veneer jointing machines, and plywood production lines, enabling continuous and automated veneer processing.
Below are common parameter ranges for industrial veneer stackers (specifications may vary by model):
| Parameter | Description |
|---|---|
| Stacking Speed | 30–100 m/min (depending on veneer thickness and machine model) |
| Maximum Stacking Height | Approx. 1000–1200 mm (adjustable) |
| Applicable Veneer Thickness | Typically 0.5–4.0 mm |
| Grading Function | Optional A/B/C grade sorting |
| Drive & Control System | Motor-driven, PLC automatic control; optional vacuum suction system |
In a complete veneer or plywood manufacturing process, the veneer stacker machine is typically positioned as follows:
Veneer Peeling Machine – Produces raw veneer sheets
Veneer Collector / Stacker – Collects, aligns, sorts, and stacks veneers
Veneer Dryer – Hot air or mesh belt dryer
Veneer Jointing / Composing Machine – Joins veneers into full-size sheets
Hot Press Machine – Presses veneers into plywood or LVL panels
The veneer collector plays a critical role in reducing manual handling, protecting veneer quality, and ensuring stable upstream and downstream production, making it an essential component of fully automated plywood production lines.
Based on production capacity and automation level, veneer stacker machines can be classified as follows:
Suitable for small to medium plywood or veneer production lines. Provides basic automatic stacking with simple operation and cost-effective performance.
Equipped with veneer grading and vacuum suction to prevent veneer curling or misalignment. Ideal for higher automation and quality requirements.
Designed for large-scale industrial plywood factories. Can be fully synchronized with peeling, drying, and composing machines for continuous, high-output production.
When sourcing veneer collector machines for export or industrial production, it is recommended to:
Clearly define production capacity (m/min or daily output) and veneer specifications (width and thickness).
Request suppliers to provide complete production line solutions to ensure seamless equipment integration.
Compare PLC control systems, automatic sorting functions, and automation levels to maximize efficiency and long-term operational value.
If required, we can assist in preparing technical specification lists, RFQ documents, and supplier comparison tables to support communication with international buyers and equipment manufacturers.
